E24002-WT1R0直動式電磁閥Janatics吉耐斯

 產品名稱：E24002-WT1R0直動式電磁閥Janatics吉耐斯
品牌：Janatics吉耐斯
產地：印度
型號：E24002-WT1R0

E24002-WT1R0直動式電磁閥Janatics吉耐斯產品詳情

端口數和位置：3/2常閉
電源：直流
電壓：24伏
線圈寬度：32毫米
孔板和壓力范圍：2NW和0-10巴
LPM中的流量：140
能量消耗：8W
安裝類型：歧管
插座外殼顏色和指示：帶有雙極LED指示燈的透明外殼可確認電源電壓-加上壓敏電阻，可為電源和負載提供過壓保護
LED顏色：紅色的
電纜連接類型：PG電纜入口
手動覆蓋：螺絲槽

E24002-WT1R0直動式電磁閥Janatics吉耐斯特征

組合安裝類型
寬范圍的線圈電壓
連續占空比
操作溫度低
無噪音性能
線圈可以360度旋轉
手動操作器（螺絲刀型）

PRODUCT DETAILS
Number Of Ports And Positions 3/2 Normally closed
Power DC
Voltage 24 V
Coil Width 32 mm
Orifice And Pressure Range 2 NW and 0-10 bar
Flowrate In LPM 140
Power Consumption 8W
Mounting Type Manifold
Socket Housing Color And Indication Transparent housing with bipolar LED Indicator confirming supply voltage - plus varistor to give over voltage protection to the source and load
LED Color Red
Electrical Cable Connection Type PG cable entry
Manual Override Screw slot

FEATURES
Gang Mounting type
Wide range of coil voltages
Continuous duty cycle
Low temperature of operation
Noiseless Performance
Coil can be rotated by 360 degree
Manual operator (Scre driver type)
